Bearing (1)
Number |
MS 27645 Dash No. |
Bore |
Outside Diameter |
Widths |
|||||
d |
D |
B |
C |
||||||
+0.0000,-.0005 +0.000,-.013 |
+0.0000,-.0005 +0.000,-.013 |
+0.000,-0.005 +0.00,-.15 |
+0.000,-.005 +0.00,-.13 |
||||||
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
||
KSP3L
|
-3A |
0.1900 |
4.826 |
0.6250 |
15.875 |
0.245 |
6.22 |
0.203 |
5.16 |
KSP4A
|
-4A |
0.2500 |
6.350 |
0.7500 |
19.050 |
0.281 |
7.14 |
0.219 |
5.56 |
KSP5A
|
-5A |
0.3125 |
7.938 |
0.8125 |
20.638 |
0.297 |
7.54 |
0.234 |
5.94 |
KSP6A
|
-6A |
0.3750 |
9.525 |
0.8750 |
22.225 |
0.313 |
7.95 |
0.250 |
6.35 |
KSP3
|
-3 |
0.1900 |
4.826 |
0.7774 |
19.746 |
0.297 |
7.54 |
0.270 |
6.86 |
KSP4
|
-4 |
0.2500 |
6.350 |
0.9014 |
22.896 |
0.484 |
12.29 |
0.335 |
8.51 |
KSP5
|
-5 |
0.3125 |
7.938 |
1.2500 |
31.750 |
0.558 |
14.17 |
0.375 |
9.52 |
KSP6
|
-6 |
0.3750 |
9.525 |
1.4375 |
36.512 |
0.620 |
15.75 |
0.469 |
11.91 |
KSP8
|
-8 |
0.5000 |
12.700 |
1.6875 |
42.862 |
0.620 |
15.75 |
0.500 |
12.70 |
KSP10
|
-10 |
0.6250 |
15.875 |
1.9375 |
49.212 |
0.813 |
20.65 |
0.625 |
15.88 |
Bearing (1) Number |
d 1
|
r 1
|
r
|
Wt.
|
Radial Limit Load Rating |
Thrust Limit Load Rating |
||||||
Approx. |
+0.015,-.000 +0.38,-.00 |
+0.015,-.000 +0.38,-.00 |
Approx. |
|||||||||
in. |
mm |
in. |
mm |
in. |
mm |
lbs. |
kg |
lbs. |
N |
lbs. |
N |
|
| KSP3L | 0.256 |
6.50 |
0.005 |
0.13 |
0.016 |
0.41 |
0.01 |
0.005 |
550 |
2450 |
100 |
450 |
| KSP4A | 0.328 |
8.33 |
0.005 |
0.13 |
0.016 |
0.41 |
0.02 |
0.009 |
900 |
4000 |
200 |
900 |
| KSP5A | 0.389 |
9.88 |
0.015 |
0.38 |
0.016 |
0.41 |
0.02 |
0.009 |
1000 |
4400 |
200 |
900 |
| KSP6A | 0.462 |
11.73 |
0.016 |
0.41 |
0.016 |
0.41 |
0.03 |
0.014 |
1120 |
5000 |
200 |
900 |
KSP3
|
0.297 |
7.54 |
0.005 |
0.13 |
0.022 |
0.56 |
0.03 |
0.014 |
900 |
4000 |
200 |
900 |
| KSP4 | 0.396 |
10.06 |
0.005 |
0.13 |
0.032 |
0.81 |
0.04 |
0.018 |
1410 |
6300 |
300 |
1340 |
| KSP5 | 0.567 |
14.40 |
0.015 |
0.38 |
0.032 |
0.81 |
0.10 |
0.045 |
2190 |
9800 |
300 |
1340 |
| KSP6 | 0.612 |
15.54 |
0.015 |
0.38 |
0.032 |
0.81 |
0.15 |
0.068 |
2980 |
13200 |
400 |
1760 |
| KSP8 | 0.796 |
20.22 |
0.015 |
0.38 |
0.044 |
1.12 |
0.23 |
0.104 |
3670 |
16300 |
500 |
2240 |
| KSP10 | 0.922 |
23.42 |
0.015 |
0.38 |
0.044 |
1.12 |
0.37 |
0.168 |
5320 |
23600 |
600 |
2650 |
(1) These bearings are self-aligning for 10° in either direction except KSP4A, KSP5A and KSP6A
which are self aligning for 8° in either direction.
Note: These bearings should not be used as track rollers, cam follower rolls, and the like.* Check for availability.
