Bearing
Number
D |
MS
27647
Dash No. |
Bore |
Outside Diameter |
Widths |
|||||
d |
D |
B |
C |
||||||
+0.0000,-.0003 +0.000,-.008 |
+0.0000,-.0004 +0.000,-.010 |
+0.0000,-0.0025
+0.000,-.064 |
+0.000,-.005 +0.00,-.13 |
||||||
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
||
MDW4K2 (1) |
-4AR |
0.2500 |
6.350 |
0.6250 |
15.875 |
0.5620 |
14.275 |
0.500 |
12.70 |
*MDW4K (1) |
-4R |
0.2500 |
6.350 |
0.7500 |
19.050 |
0.8750 |
22.225 |
0.750 |
19.05 |
*MDW4 |
- |
0.2500 |
6.350 |
0.7500 |
19.050 |
0.8750 |
22.225 |
0.750 |
19.05 |
MDW5 |
-5R |
0.3125 |
7.938 |
0.8750 |
22.225 |
0.9380 |
23.825 |
0.813 |
20.65 |
MDW6 |
-6R |
0.3750 |
9.525 |
1.0625 |
26.988 |
1.1880 |
30.175 |
1.063 |
27.00 |
MDW8 |
-8R |
0.5000 |
12.700 |
1.4375 |
36.512 |
1.5000 |
38.100 |
1.375 |
34.92 |
*MDPP3 |
- |
0.1900 |
4.826 |
0.7774 |
19.746 |
0.4950 |
12.570 |
0.473 |
12.01 |
MDPP4 |
- |
0.2500 |
6.350 |
0.9014 |
22.896 |
0.6200 |
15.750 |
0.491 |
12.47 |
MDPP5 |
- |
0.3125 |
7.938 |
1.2500 |
31.750 |
0.7450 |
18.920 |
0.687 |
17.45 |
*MDPP6 |
- |
0.3750 |
9.525 |
1.4375 |
36.512 |
0.8700 |
22.100 |
0.794 |
20.17 |
*MDPP8 |
- |
0.5000 |
12.700 |
1.6875 |
42.862 |
0.9320 |
23.670 |
0.856 |
21.74 |
*MDPP10 |
- |
0.6250 |
15.875 |
1.9375 |
49.212 |
0.9950 |
25.270 |
0.920 |
23.37 |
MS27643 |
|||||||||
MDSP3 (2) |
-3R |
0.1900 |
4.826 |
0.7774 |
19.746 |
0.5000 |
12.700 |
0.392 |
9.96 |
MDSP4 (2) |
-4R |
0.2500 |
6.350 |
0.9014 |
22.896 |
0.6870 |
17.450 |
0.464 |
11.79 |
MDSP5 (2) |
-5R |
0.3125 |
7.938 |
1.2500 |
31.750 |
0.8120 |
20.620 |
0.656 |
16.66 |
MDSP6 (2) |
-6R |
0.3750 |
9.525 |
1.4375 |
36.512 |
0.9370 |
23.800 |
0.750 |
19.05 |
*MDSP8 (2) |
-8R |
0.5000 |
12.700 |
1.6875 |
42.862 |
1.0000 |
25.400 |
0.812 |
20.62 |
*MDSP10 (2) |
-10R |
0.6250 |
15.875 |
1.9375 |
49.212 |
1.1250 |
28.580 |
0.937 |
23.80 |
Bearing Number D |
MS 27647 Dash No. |
d 1 |
r 1 |
r |
Wt. |
Radial Limit Load Rating |
Thrust Limit Load Rating |
||||||
| Approx. |
+0.015,-.000 +0.38,-.00 |
+0.015,-.000 +0.38,-.00 |
Approx. |
||||||||||
in. |
mm |
in. |
mm |
in. |
mm |
lbs. |
kg |
lbs. |
l\l |
lbs. |
N |
||
MDW4K2 (1) |
-4AR |
0.339 |
8.61 |
0.005 |
0.13 |
0.016 |
0.41 |
0.025 |
0.011 |
1400 |
6200 |
500 |
2240 |
*MDW4K (1) |
-4R |
0.380 |
9.65 |
0.005 |
0.13 |
0.016 |
0.41 |
0.04 |
0.018 |
2770 |
12200 |
900 |
4000 |
*MDW4 |
- |
0.375 |
9.52 |
0.005 |
0.13 |
0.016 |
0.41 |
0.06 |
0.027 |
3750 |
16600 |
1240 |
5500 |
MDW5 |
-5R |
0.469 |
11.91 |
0.005 |
0.13 |
0.016 |
0.41 |
0.07 |
0.032 |
5140 |
22800 |
1600 |
7100 |
MDW6 |
-6R |
0.573 |
14.55 |
0.005 |
0.13 |
0.016 |
0.41 |
0.12 |
0.054 |
8440 |
37500 |
2600 |
11600 |
MDW8 |
-8R |
0.712 |
18.08 |
0.005 |
0.13 |
0.032 |
0.81 |
0.29 |
0.132 |
15520 |
69500 |
4700 |
20800 |
*MDPP3 |
- |
0.302 |
7.67 |
0.005 |
0.13 |
0.018 |
0.46 |
0.04 |
0.018 |
2950 |
13200 |
1700 |
7500 |
MDPP4 |
- |
0.410 |
10.41 |
0.005 |
0.13 |
0.032 |
0.81 |
0.06 |
0.027 |
5370 |
24000 |
1800 |
8000 |
MDPP5 |
- |
0.469 |
11.91 |
0.015 |
0.38 |
0.032 |
0.81 |
0.17 |
0.077 |
11000 |
49000 |
4000 |
17600 |
*MDPP6 |
- |
0.551 |
14.00 |
0.015 |
0.38 |
0.032 |
0.81 |
0.26 |
0.118 |
15760 |
69500 |
5300 |
23600 |
*MDPP8 |
- |
0.735 |
18.67 |
0.015 |
0.38 |
0.044 |
1.12 |
0.38 |
0.172 |
23600 |
1E+05 |
7800 |
34500 |
*MDPP10 |
- |
0.890 |
22.61 |
0.015 |
0.38 |
0.044 |
1.12 |
0.53 |
0.240 |
28400 |
1E+05 |
9400 |
41500 |
MS27643 |
|||||||||||||
MDSP3 (2) |
-3R |
0.304 |
7.72 |
0.005 |
0.13 |
0.022 |
0.56 |
0.04 |
0.018 |
1420 |
6400 |
200 |
900 |
MDSP4 (2) |
-4R |
0.430 |
10.92 |
0.005 |
0.13 |
0.032 |
0.81 |
0.06 |
0.027 |
1780 |
8000 |
300 |
1340 |
MDSP5 (2) |
-5R |
0.515 |
13.08 |
0.015 |
0.38 |
0.032 |
0.81 |
0.16 |
0.073 |
3740 |
16600 |
600 |
2650 |
MDSP6 (2) |
-6R |
0.564 |
14.33 |
0.015 |
0.38 |
0.032 |
0.81 |
0.24 |
0.109 |
5100 |
22800 |
800 |
3550 |
*MDSP8 (2) |
-8R |
0.775 |
19.68 |
0.015 |
0.38 |
0.044 |
1.12 |
0.36 |
0.163 |
7120 |
31500 |
1000 |
4400 |
*MDSP10 (2) |
-10R |
0.869 |
22.07 |
0.015 |
0.38 |
0.044 |
1.12 |
0.53 |
0.240 |
9000 |
40000 |
1300 |
5850 |
(1) Retainer type.
(2) These bearings are self-aligning for 10° in either direction
Note: These bearings should not be used as track rollers, cam follower rolls, and the like.
* Check for availability
