Bearing Number |
MS 27640 Dash No. |
Bore |
Outside Diameter |
Widths |
|||||
d |
D |
B |
C |
||||||
+0.0000,-.0003 +0.000,-.008 |
+0.0000,-.0004 +0.000,-.010 |
+0.0000,-.0025 +0.000,-.064 |
+0.000,-.005 +0.00,-.13 |
||||||
in. |
mm |
in. |
mm |
in. |
mm |
in. |
mm |
||
MKP3 |
-3R |
0.1900 |
4.826 |
0.7774 |
19.746 |
0.297 |
7.54 |
0.270 |
6.86 |
MKP4 |
-4R |
0.2500 |
6.350 |
0.9014 |
22.896 |
0.484 |
12.29 |
0.335 |
8.51 |
MKP5 |
-5R |
0.3125 |
7.938 |
1.2500 |
31.750 |
0.558 |
14.17 |
0.375 |
9.52 |
MKP6 |
-6R |
0.3750 |
9.525 |
1.4375 |
36.512 |
0.620 |
15.75 |
0.469 |
11.91 |
MKP8 |
-8R |
0.5000 |
12.700 |
1.6875 |
42.862 |
0.620 |
15.75 |
0.500 |
12.70 |
MKP10 |
-10R |
0.6250 |
15.875 |
1.9375 |
49.212 |
0.620 |
15.75 |
0.500 |
12.70 |
Bearing
Number
|
d 1 |
r 1 |
r |
Wt. |
Radial
Limit Load Rating |
Thrust
Limit Load Rating |
||||||
|
Approx. |
+0.015,-.000
+0.38,-.00 |
+0.015,-.000
+0.38,-.00 |
Approx. |
|||||||||
in. |
mm |
in. |
mm |
in. |
mm |
lbs |
.kg |
lbs. |
N |
lbs. |
N |
|
MKP3 |
0.331 |
8.41 |
0.005 |
0.13 |
0.022 |
0.56 |
0.03 |
0.014 |
1880 |
8300 |
900 |
4000 |
MKP4 |
0.387 |
9.83 |
0.005 |
0.13 |
0.032 |
0.81 |
0.04 |
0.018 |
2680 |
12000 |
1200 |
5300 |
MKP5 |
0.469 |
11.91 |
0.015 |
0.38 |
0.032 |
0.81 |
0.09 |
0.041 |
5620 |
25000 |
2500 |
11200 |
MKP6 |
0.591 |
15.01 |
0.015 |
0.38 |
0.032 |
0.81 |
0.15 |
0.068 |
7910 |
35500 |
3500 |
15600 |
MKP8 |
0.752 |
19.10 |
0.015 |
0.38 |
0.044 |
1.12 |
0.21 |
0.095 |
11810 |
52000 |
5200 |
23200 |
MKP10 |
0.850 |
21.59 |
0.015 |
0.38 |
0.044 |
1.12 |
0.28 |
0.127 |
14100 |
63000 |
6200 |
27500 |
Note: These bearings should not be used as track rollers, cam follower rolls, and the like.
* Check for availability
